Lithium Battery Solutions for Portable Air Pumps

Industry Background

Portable air pumps are essential outdoor tools used in camping, cycling, automotive emergencies, SUP boards, and travel applications.
These compact devices rely heavily on battery performance to deliver strong airflow, stable pressure output, and continuous operation.

As features such as digital pressure control, auto-stop functions, USB-C charging, LED lighting, and power-bank output become mainstream,
selecting the right lithium battery chemistry and discharge capability is critical.

PKNERGY provides high-drain lithium-ion battery solutions designed specifically for portable air pump applications,
offering up to 10C discharge using standard high-rate 18650 and 21700 cells.

Key Pain Points in Portable Air Pump Batteries

1. High Startup Current

BLDC motors require sudden bursts of high current. Many air pumps demand 8A–20A instantaneous current.
PKNERGY’s 10C cells handle peak loads without voltage sag or system reset.

2. Long Runtime Expectations

Users expect multiple tire inflations or several hours of continuous use.
High-capacity 18650 and 21700 cells provide excellent energy density for extended runtime.

3. Operating Temperature Challenges

Heat from BLDC motors and compression chambers requires batteries with strong thermal stability.
PKNERGY high-rate cells maintain consistent output during extended operation.

4. Multi-Functional Power Loads

• Digital displays & MCUs
• Pressure sensors
• LED lighting
• USB power-bank output

These additional loads demand stable voltage and reliable discharge capability.

5. Compact Design Constraints

Designers must integrate batteries, motors, driver boards, and airflow systems into compact enclosures.
Cylindrical lithium cells offer predictable dimensions and easy assembly.

PKNERGY Solution Value

• 10C high-drain capability for BLDC motors
• High-capacity options: 18650 (2000–3500mAh), 21700 (4000–5000mAh)
• Excellent thermal stability for continuous operation
• Custom pack configurations: 1S1P, 1S2P, 1S3P, 1S4P
• Integrated BMS protection with NTC temperature monitoring

Learn more about our
Custom LiFePO4 Battery and
Custom Lithium Polymer Battery solutions.

Technical Insights

Recommended High-Rate Cell Models

• 18650-2000mAh-10C — high-drain performance
• 18650-2500mAh-10C — balanced capacity & power
• 21700-4000mAh-10C — extended runtime with strong discharge
• 21700-5000mAh-8C — long-duration inflation applications

Battery System Architecture

• 3.7V lithium-ion battery pack
• BLDC motor driver & MOSFET stage
• Pressure sensor + digital control unit
• USB-C charging IC + BMS protection
• Optional boost converter for power-bank mode

Mechanical Integration Guidelines

• Place battery near ventilation paths for passive cooling
• Use reinforced nickel strips rated >20A pulse load
• Add anti-vibration brackets for outdoor use
• Recommended connectors: XT30, XT60, reinforced JST




Application Use Cases

• Automotive tire inflators
• Bicycle & motorcycle air pumps
• SUP board inflation
• Camping mattresses & inflatable pillows
• Emergency roadside equipment
• Portable multifunction air pumps

Explore related solutions:
Consumer Electronics Power Solution ·
Solar Lighting Power Solution
