Lightweight, long-life, and temperature-resilient battery packs purpose-built for mobile, off-grid and smart HVAC condenser systems.
With the global trend toward energy-efficient and portable HVAC systems, reliable DC power solutions are becoming essential. Air conditioner condensers—especially for RV A/C, portable cooling units, and solar-powered HVAC—demand compact packs with high efficiency, stable output, and strong protection.
Application Background
Condenser subsystems (compressor, fan motor, control board) require continuous, stable DC power. Compared with lead-acid, prismatic lithium packs offer:
- Higher energy density and discharge efficiency
- Wide working temperature and better high-temp endurance (up to 55–60 °C)
- Long cycle life (>2000 cycles typical for LiFePO4)
- Stable voltage with robust BMS/PCM
PKNERGY Battery Solution
PKNERGY provides 3.7 V prismatic cells (10–60 Ah) and custom 12 V / 24 V condenser battery modules.
Key Features
- Chemistry: NCM or LiFePO4 (temperature stability & longevity)
- Voltage options: 3.7 V, 7.4 V, 12.8 V, 24 V (custom)
- BMS protection: over-charge/over-discharge/over-current/short-circuit
- Mechanical: aluminum housing, quick-connect terminals, optional waterproof casing
- Certifications: UN38.3, CE, IEC62133, RoHS
Why Prismatic Cells
- Excellent packing efficiency for slim HVAC compartments
- Lower internal resistance for compressor startup loads
- Consistent module voltage with tight cell matching
Explore our custom lithium battery packs and engineering services.
Value for Buyers & Engineers
- Lower total cost of ownership via long cycle life and minimal maintenance
- Low MOQ, rapid prototyping, and flexible OEM/ODM tailoring
- In-house cell manufacturing + pack assembly = faster delivery
- Electrical/mechanical integration support with control boards and cooling systems
- Global compliance and safe transport (UN38.3, CE, IEC62133)
Case Study
Scenario: European portable A/C brand replaced lead-acid with a 12 V 40 Ah prismatic module.
- Weight ↓ ~45%
- Energy efficiency ↑ ~30%
- Stable running at 55 °C ambient
- Service life ~2.5× vs. previous solution
Recommended Specs & Configuration
| Item | Recommendation | Notes / Links |
|---|---|---|
| Cell Chemistry | LiFePO4 (safety & cycle life) / NCM (higher energy) | LiFePO4 Packs |
| Nominal Voltage | 12.8 V or 24 V module | Custom Modules |
| Capacity Options | 10–60 Ah cell base; pack 20–100 Ah typical | Tailored by duty cycle & runtime |
| Discharge | High pulse for compressor start + steady 0.5–1C | BMS with current limiting |
| Temperature Range | -20 °C ~ 60 °C (design-dependent) | BMS Options |
| Enclosure | Aluminum housing, IP-rated, quick-connect terminals | HVAC-friendly footprint |
| Compliance | UN38.3, CE, IEC62133, RoHS | Company Profile |
Related Solutions & Products:
FAQ
Can the pack handle compressor inrush current?
Yes. We configure cell IR, busbar design, and BMS current limits for safe startup. High-pulse capability can be validated on your compressor profile.
Which chemistry should I choose for condensers?
Choose LiFePO4 for safety and cycle life; NCM for tighter space with higher energy density. We can simulate runtimes for both.
What about operation in high ambient temperatures?
Designs target up to 55–60 °C ambient with appropriate derating. We recommend thermal paths and enclosure options for hot compartments.
Do you support certifications?
Yes. Packs are designed for UN38.3 transport; CE/IEC62133 per project needs. We assist with test plans and documentation.
Next Step
Share your condenser specs (voltage, steady/pulse current, ambient temperature, target runtime, envelope size). We’ll return a fit-for-purpose pack proposal within one working day.
