Lithium-ion Battery Pack

C8574170HP 3.5V 23000mAh

Provides a nominal capacity of 23,000mAh and a minimum capacity of 21,900mAh when tested at a 0.2C discharge rate.

The combination of 3.5V nominal voltage and 23Ah capacity provides approximately 80.5Wh of nominal energy per cell.

Supports a maximum continuous discharge current of 69A, suitable for applications with sustained high-current demand.

Provides up to 115A burst discharge for a maximum of 10 seconds, supporting temporary peak loads such as motor startup and rapid power acceleration.

The initial AC internal resistance is specified at no more than 1.6mΩ when measured at 1kHz and approximately 50% SOC.

With a maximum thickness of only 8.8mm, the cell can help engineers build thin and compact high-power battery modules.

Supports charging at up to 11.5A, with a reference rapid charging time of approximately three hours.

No.	Item	Specification	Remarks
1	Battery Type	Rechargeable lithium-ion polymer pouch cell	Bare cell
2	Model	SDL-C8574170HP	—
3	Configuration	1S1P	Single cell
4	Nominal Capacity	23,000mAh	0.2C discharge
5	Minimum Capacity	21,900mAh	0.2C discharge
6	Nominal Voltage	3.5V	—
7	Nominal Energy	Approx. 80.5Wh	3.5V × 23Ah
8	Charge Voltage	4.20 ±0.02V	CC/CV charging
9	Standard Charge Current	0.2C / 4.6A	According to the main specification table
10	Rapid Charge Current	0.5C / 11.5A	—
11	Maximum Charge Current	0.5C / 11.5A	—
12	Standard Charging Time	Approx. 6 hours	Reference value
13	Rapid Charging Time	Approx. 3 hours	Reference value
14	Continuous Discharge Current	3C / 69A	Maximum specified continuous current
15	Burst Discharge Current	5C / 115A	Maximum 10 seconds
16	Discharge Cut-off Voltage	2.5V	Per cell
17	Initial Internal Resistance	≤1.6mΩ	AC 1kHz, approximately 50% SOC
18	Charging Temperature	0°C to 45°C	—
19	Discharging Temperature	0°C to 45°C	—
20	Cell Weight	Approx. 245g	—
21	Maximum Dimensions	8.8 × 74.5 × 172mm	Thickness × width × length
22	Short-Term Storage Temperature	0°C to 35°C	Less than one month
23	Long-Term Storage Temperature	10°C to 25°C	More than one month
24	Ex-factory SOC	At least 50%	OCV not lower than 3.8V

Electrochemical performance characteristics

Test Item	Performance Requirement	Test Condition
Standard Discharge Capacity	≥21,900mAh	4.6A discharge to 2.5V at 25 ±5°C
Cycle Life	300 cycles	Tested at 0.5C charge and discharge
Capacity after 300 Cycles	≥17,520mAh	At least 80% of initial minimum capacity
Initial Internal Resistance	≤1.6mΩ	AC 1kHz at approximately 50% SOC
28-Day Storage Capacity	≥18,615mAh	Stored for 28 days at 25°C
Storage Capacity Retention	≥85%	Based on the initial capacity
Shipment SOC	≥50%	OCV ≥3.8V
