CINEMA DRONE BATTERY
High-Voltage & High-Rate LiPo Pouch Battery Solutions for Professional Aerial Cinematography
PKNERGY Cinema Drone Battery Solutions
PKNERGY provides high-voltage and high-rate lithium polymer (LiPo) pouch battery solutions for professional cinematography and imaging UAVs. Designed for demanding flight loads and professional camera systems, our battery solutions support different aircraft configurations, payload requirements, and power architectures.
High-Voltage High-Rate LiPo Pouch Batteries are suitable for compatible high-voltage propulsion systems and demanding power requirements, while High-Rate LiPo Pouch Batteries offer responsive current delivery for dynamic aerial filming and professional imaging applications.
From professional quadcopters and cinema-grade multirotors to heavy-lift Cine-lifters and broadcast UAVs, PKNERGY can customize voltage, capacity, discharge performance, connectors, and battery monitoring options to match your aircraft and production workflow.
● High-Voltage Power System
High-voltage LiPo pouch battery options support compatible propulsion systems and demanding professional imaging platforms, helping optimize power delivery and electrical system integration.
● High-Rate Discharge Performance
Powerful output for demanding flight loads High-rate LiPo pouch batteries support takeoff peaks, rapid maneuvers, and the power demands of professional camera and gimbal systems.
● Lightweight Design & Payload Flexibility
Compact pouch-cell construction helps optimize battery size and weight, supporting payload planning for professional cameras, lenses, gimbals, and imaging accessories.
● Customized Battery Configurations
Flexible voltage, capacity, and integration options support professional quadcopters, cinema-grade multirotors, dual-battery Cine-lifters, broadcast UAVs, and interchangeable-payload platforms.
Battery Requirements for Different Cinema Drone Applications
Professional Aerial Photography Quadcopter Battery Solutions
Battery Requirements
- Smart BMS and accurate state-of-charge (SOC) monitoring
- Stable power for cameras, gimbals, and imaging payloads
- Low-temperature performance evaluation
- Quick-release battery design and charging case compatibility
Recommended Battery Configuration
Battery Type: High-Rate LiPo Pouch Battery or High-Voltage High-Rate LiPo Pouch Battery
Voltage Platform: 6S–12S
Energy Range: 150–350Wh
Continuous Discharge Current: 50–120A
Peak Discharge Current: 150–250A
Cinema-Grade Hexacopters & Octocopter Battery Solutions
Battery Requirements
- High current output for heavy camera payloads and takeoff peaks
- Redundant battery system design where required
- Anti-spark connections and high-current power distribution
- Power support for gimbals and video transmission equipment
Recommended Battery Configuration
Battery Type: High-Voltage High-Rate LiPo Pouch Battery
Voltage Platform: 6S–12S
Energy Range: 300–1,200Wh
Continuous Discharge Current: 100–300A
Peak Discharge Current: 300–500A
Heavy-Lift Dual-Battery Cine-Lifter Battery Solutions
Battery Requirements
- Matched dual-battery packs for balanced operation
- Synchronized SOC monitoring and fault isolation
- Secure locking and temperature monitoring
- CAN communication and high-current system integration
Recommended Battery Configuration
Battery Type: High-Voltage High-Rate LiPo Pouch Battery
Voltage Platform: Dual 12S
Capacity: 10–20Ah per pack
Total Energy Range: Approx. 0.9–1.8kWh
Continuous Discharge Current: 180–320A per pack
Integration Options: Pack matching, SOC synchronization, fault isolation, CAN communication, and temperature monitoring
Live Broadcasting & Broadcast UAV Battery Solutions
Battery Requirements
- Continuous power for cameras, encoders, and video transmission systems
- Stable power delivery during extended live broadcasts
- Low-noise electrical supply and thermal management
- Reliable integration with professional imaging equipment
Recommended Battery Configuration
Battery Type: High-Rate LiPo Pouch Battery or High-Voltage High-Rate LiPo Pouch Battery
Voltage Platform: 6S–12S
Energy Range: 200–800Wh
Continuous Discharge Current: 60–180A
Peak Discharge Current: Up to 250A
High-Altitude & Winter Filming Drone Battery Solutions
Battery Requirements
- Low-temperature preheating and discharge performance evaluation
- Temperature confirmation before takeoff
- Altitude-related power derating assessment
- Thermal management for cold-weather filming operations
Recommended Battery Configuration
Battery Type: High-Rate LiPo Pouch Battery or High-Voltage High-Rate LiPo Pouch Battery
Voltage Platform: 6S–12S
Energy Range: 180–600Wh
Continuous Discharge Current: 60–150A
Integration Options: Optional preheating, temperature monitoring, and application-specific altitude derating evaluation
Interchangeable-Payload UAV Battery Solutions
Battery Requirements
- Compatibility with different camera and payload configurations
- Energy budgeting based on payload power consumption
- Mechanical compatibility and secure battery installation
- Battery health monitoring and data-interface integration
Recommended Battery Configuration
Battery Type: High-Voltage High-Rate LiPo Pouch Battery or High-Rate LiPo Pouch Battery
Voltage Platform: 12S
Energy Range: 250–800Wh
Continuous Discharge Current: 80–200A
Peak Discharge Current: Up to 300A
Integration Options: Payload identification, energy budgeting, data interfaces, mechanical compatibility, and SOH monitoring
High Rate Pouch UAV Battery Specifications
High-Voltage High-Rate Pouch UAV Battery Specifications
Process
Request a Quote
