FPV DRONE BATTERY
High-Rate Pouch Battery Solutions for FPV Racing, Freestyle & Cinewhoop Drones
PKNERGY FPV Drone Battery Solutions
PKNERGY provides high-rate pouch battery solutions designed for FPV racing, freestyle flying, and high-performance aerial platforms. Engineered for demanding power bursts, rapid throttle response, and agile flight control, our lightweight pouch batteries deliver high discharge capability in compact form factors.
With continuous discharge rates of up to 90C on selected models, PKNERGY supports FPV platforms that demand explosive acceleration, responsive maneuverability, and reliable power delivery during aggressive flight operations.
● Ultra-High Discharge Rate
Up to 90C continuous discharge supports rapid current delivery for aggressive acceleration, sharp turns, and demanding FPV flight maneuvers.
● Compact Size & Lightweight Design
Lightweight pouch battery design helps reduce battery size and weight, improving agility and power-to-weight ratio for compact FPV platforms.
● Explosive Power & Fast Response
High-rate power delivery supports rapid throttle changes, dynamic flight maneuvers, and responsive control during demanding FPV operations.
● Customized Battery Configurations
Flexible voltage, capacity, and connector options support diverse FPV applications, from compact 3-inch Cinewhoops to high-power racing drones and larger Cine-lifter platforms.
Battery Requirements for Different FPV Applications
3-Inch Cinewhoop Drone Battery Solutions
Battery Requirements
- Compact size and lightweight construction
- Low internal resistance for responsive power delivery
- Secure pouch-cell packaging and impact protection
- XT30 connector compatibility
Recommended Battery Configuration
Voltage Platform: 4S
Capacity Range: 650–1,100mAh
Energy Range: Approx. 10–18Wh
Continuous Discharge Current: 35–70A
Peak Discharge Current: 80–120A
5-Inch Racing & Freestyle Drone Battery Solutions
Battery Requirements
- High discharge rate for rapid acceleration
- Reliable cell tabs and welded connections
- XT60 connector compatibility
- Controlled voltage sag and temperature rise
- Consistent cell performance under high loads
Recommended Battery Configuration
Voltage Platform: 6S
Capacity Range: 1,000–1,800mAh
Energy Range: Approx. 22–40Wh
Continuous Discharge Current: 80–140A
Peak Discharge Current: 150–220A
7-Inch Long-Range FPV Drone Battery Solutions
Battery Requirements
- Balanced energy density and peak power output
- Stable performance across changing temperatures
- Sufficient energy reserves for GPS-assisted return
- Reliable power delivery during extended missions
Recommended Battery Configuration
Voltage Platform: 6S Li-ion / LiPo
Capacity Range: 3,000–6,000mAh
Energy Range: Approx. 65–135Wh
Continuous Discharge Current: 35–80A
Peak Discharge Current: 90–140A
8–10-Inch Cine-Lifter Drone Battery Solutions
Battery Requirements
- High-current power delivery for heavy camera payloads
- High-current connectors and anti-spark solutions
- Secure battery mounting and vibration resistance
- Properly engineered series or parallel battery configurations
Recommended Battery Configuration
Voltage Platform: 6S–12S
Capacity Range: 5,000–16,000mAh
Energy Range: Approx. 110–700Wh
Continuous Discharge Current: 100–250A
Peak Discharge Current: 250–400A
Indoor Caged & Inspection FPV Drone Battery Solutions
Battery Requirements
- Impact-resistant enclosure and secure cell protection
- Short-duration high-power delivery
- Effective thermal management
- Quick battery replacement
- Clear battery status indication
Recommended Battery Configuration
Voltage Platform: 4S–6S
Capacity Range: 2,000–5,000mAh
Energy Range: Approx. 30–110Wh
Continuous Discharge Current: 50–120A
Peak Discharge Current: Up to 150A
FPV Goggles & Ground Equipment
Battery Requirements
- Stable low-current power supply
- Portable design for field operation
- State-of-charge monitoring
- USB-C PD compatibility where supported by the system
- Reliable power for extended ground operations
Recommended Battery Configuration
Voltage Platform: 2S–4S
Capacity Range: 2,000–6,000mAh
Energy Range: Approx. 15–90Wh
Continuous Discharge Current: 2–8A
High Rate Pouch UAV Battery Specifications
