HEAVY-LIFT DRONE BATTERY
Semi-Solid-State High Energy Density UAV Battery Solutions for Cargo Delivery, Heavy-Payload & Industrial UAVs
PKNERGY Heavy-Lift Drone Battery Solutions
PKNERGY provides Semi-Solid-State High Energy Density UAV Battery solutions for heavy-lift drones, cargo delivery UAVs, medical logistics, winch operations, and other demanding industrial applications. Designed around payload capacity, flight endurance, and power requirements, our customized battery packs support different voltage platforms, energy capacities, and multi-pack configurations.
Selected battery models offer energy density of up to 450 Wh/kg. Voltage, capacity, discharge performance, and pack design can be customized according to the UAV platform and mission requirements.
● Higher Energy Density
More Energy with Less Weight Selected Semi-Solid-State High Energy Density UAV Battery models offer up to 450 Wh/kg, helping support payload and endurance targets where the selected configuration is suitable.
● High-Power Output
Designed for Demanding Missions Battery configurations can be evaluated against continuous current, peak current, takeoff loads, and other mission-specific power demands.
● Customized Multi-Pack Integration
Flexible System Configuration Single-pack and multi-pack designs can be tailored to aircraft voltage, energy capacity, installation space, and redundancy requirements.
● Battery Monitoring & Protection
Reliable System Integration Customized BMS functions can support voltage and temperature monitoring, state-of-health tracking, communication, and protection features based on project requirements.
Battery Requirements for Different Heavy-Lift UAV Applications
Small Last-Mile Delivery Drone Battery Solutions
Battery Requirements
- Stable power delivery for repeated delivery routes
- Quick battery replacement and pack identification
- Energy reserve for payload and weather variations
- Battery health monitoring for fleet operation
Recommended Battery Configuration
Voltage Platform: 6S–12S
Energy Range: 300–800 Wh
Continuous Discharge Current: 80–180 A
Peak Discharge Current: Up to 250 A
Medical Sample & Pharmaceutical Delivery VTOL Drone Battery Solutions
Battery Requirements
- Reliable energy reserve for VTOL takeoff and landing
- Traceable battery status for mission management
- Support for temperature-controlled payload systems
- Performance evaluation under low-temperature conditions
Recommended Battery Configuration
Voltage Platform: 6S–12S
Energy Range: 300–1,500 Wh
Continuous Discharge Current: 40–150 A
VTOL Peak Current: Up to 220 A
5–20 kg Cargo Drone Battery Solutions
Battery Requirements
- High-current output for takeoff and heavy-payload flight
- Multi-pack support and current monitoring where required
- Secure mechanical locking and anti-spark connections
- Thermal management under sustained high loads
Recommended Battery Configuration
Voltage Platform: 12S–14S
Energy Range: 1–3 kWh
Continuous Discharge Current: 150–350 A
Peak Discharge Current: Up to 450 A
20–50 kg Heavy-Lift Drone Battery Solutions
Battery Requirements
- High energy capacity for heavy-payload missions
- Multi-pack redundancy and current-sharing evaluation
- High-voltage insulation and connector temperature monitoring
- Fault isolation and mission energy reserve planning
Recommended Battery Configuration
Voltage Platform: 12S–20S
Energy Range: 2–6 kWh
Continuous Discharge Current: 250–600 A
Battery Configuration: Multi-pack redundant system, subject to system design
Winch & Suspended-Load Drone Battery Solutions
Battery Requirements
- Power support for combined flight and winch loads
- Evaluation of transient current during lifting operations
- Secure battery installation for suspended-load missions
- Multi-pack redundancy where required by the platform
Recommended Battery Configuration
Voltage Platform: 12S–20S
Energy Range: 1–4 kWh
Continuous Discharge Current: 180–450 A
Winch Peak Current: To be confirmed according to the winch system
Firefighting & Emergency Heavy-Lift UAV Battery Solutions
Battery Requirements
- Power and energy evaluation for specialized emergency payloads
- Thermal performance assessment under demanding conditions
- Redundancy and fault-management planning
- System-level safety and operational risk assessment
Recommended Battery Configuration
Voltage Platform: 14S–20S
Energy Range: 3–10 kWh
Discharge Current: Determined by system-level evaluation
Battery Solution: Customized Semi-Solid-State High Energy Density UAV Battery system
Hot-Swappable Fleet Battery System Solutions
Battery Requirements
- Secure locking and interlocks to prevent unintended disconnection
- Pre-charge and communication handshake support where required
- Battery identification and health-status monitoring
- Safe replacement procedures for fleet operations
Recommended Battery Configuration
Voltage Platform: 6S–14S
Energy Range: 300 Wh–2 kWh
Discharge Current: Confirmed according to the UAV platform
Integration: Customized pack identification, communication, and interlock functions
Semi-Solid-State High Energy Density UAV Battery Specifications
